Globally leading security solution for the safe protection of network infrastructures
Radware FireEye hp Vectra Rapid7
FireEye

APT Security solution (No.1 Signature-less Malware Protection)

MANDIANT

Mandiant service is ambulatory technical strength, experience, service to investigate the evidence of infringement on the basis of intelligence, to the methodology.

Threat IntelligenceThreat Intelligence Retention attack tools, methodology and indicators of intent infringement trail (Indicators of Compromise) of the main attack group
TechnologyTechnology Check the evidence of infringement accident of thousands of the host, using a rapid investigation capable own tool traces of network infringement
Investigative SkillsInvestigative Skills Using the infringement accident investigation techniques and methodologies obtained through a number of infringement accident investigation study
Management ExperienceManagement Experience On the basis of a variety of consulting services experience, provide a guide and advice for the security threats of the company
Dedicated Malware TeamDedicated Malware Team It maintains its own team to run the only analysis of malware and the latest abuse

NX Series

Model NX900 NX1400 NX2400 NX4400(4420) NX7400(7420) NX10000
Vx Engine(FEOS7.0) 4 8 24 48 192
Users 50 100 500 2500 10000 40000
Performance Up to 10Mbps Up to 20Mbps Up to 50Mbps Up to 250Mbps Up to 1Gbps Up to 4Gbps
Rack Half-1U Rack-Mount 1U Rack-Mount 2U Rack-Mount
Dimensions 16.8"x14.0"x1.7" 17.2"x25.6"x1.7" 17.2"x25.6"x3.5" 17.2"x27.9"x3.5"
weight 17 lbs (7.7Kg) 22 lbs (9.9Kg) 30 lbs (13.6Kg) 50 lbs (22.7Kg) 60 lbs (27.2Kg)
Processor Type 2.3GHz/8-Core 3.1GHz/6-Core 3.2GHz/8-Core 2.5GHz/16-Core
Cores 8 6 8 32 64
Nums 1 2 4
Memory 16GB 32GB 64GB 256GB
HDD 1x500GB SATA 2x600GB SAS Drive 2 x 800GB SAS Drive
Bypass Card/NIC YES
P/S 1 (Single 200W) 2 (Single 260W) 2 (Dual 700W) 2 (Dual 1200W)
Monitoring ports 2x10/100/1000 Base-T 4x10/100/1000 Base-T 4x1000 Base-T(1000Base-SX) 2x10G Base-SR/SW
Management ports 2x10/100/1000 Base-T
RAID No RAID 1

AX Series

Model AX5400 AX8400
Vx Engine(FEOS7.0) 48 96
Performance Up to 8,200 / Day Up to 16,000 / Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 16 32
Nums 2
Memory 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Management ports 2x10/100/1000 Base-T
RAID RAID 1

EX Series

Model EX3400 EX5400 EX8400(8420)
Vx Engine(FEOS7.0) 48 96 160
Performance 150,000 Emails/Day 400,000 Emails/Day 750,000 Emails/Day
Performance(TLS) 100,000 Emails/Day 270,000 Emails/Day 500,000 Emails/Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 25 lbs (11.4 Kg) 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 8 16 32
Nums 1 2
Memory 32GB 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Monitoring ports 2x10/100/1000 Base-T 2x1000 Base-T(1000Base-SX)
Management ports 2x10/100/1000 Base-T
RAID RAID 1

FX Series

Model FX5400 FX8400
Vx Engine(FEOS7.0) 96 192
Performance Up to 80,000 Files/Day Up to 160,000 Files/Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 16 32
Nums 2
Memory 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Management ports 2x10/100/1000 Base-T

CM Series

Model CM4400 CM7400 CM9400
Performance Up to 16 Web appliances (12 Web / 1 eMAil / 1 MAS) Up to 40 Web appliances (26 Web / 3 eMail / 1 MAS) Up to 100 Web appliances (48 Web / 5 eMail / 1 MAS)
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x25.6"x3.4"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 8 16 32
Nums 1 2
Memory 64GB 128GB 256GB
HDD 4x600GB SAS Drive 4x800GB SAS Drive
P/S 2 (Dual 700W)
Management ports 2 (Dual 700W)
RAID RAID 10
