Network Infrastructure Solution
Network Infrastructure Solution

Network Infrastructure Solution
Globally leading network infrastructure solution: L4-L7 Load Balancing, WAN acceleration, intelligent traffic management, DNS/DHCP/IP management
F5 Networks Radware Alteon Brocade Packetlogic Infoblox
Brocade
  • Phone
    Head of DepartmentLee WoominT. +82-2-3404-5665
  • Email

Provide Integrated Networking Solution through SAN Infra Solution, IP router and switch

Ethernet Enterprise Switch

Categories Work group switch Backbone switch Backbone Router
(up to 16 slots) (up to 32 slots)
FastIron CX 624S/648S/624S-F FastIron ICX 6430/6450/6610 FastIron ICX 6650 FastIron ICX 7750 FastIron SX 800/1600 NetIron MXLe-4/8
Switch Fabric Capacity 152/200/152Gbps 104/176/576Gbps 1600Gbps 1.92Tbps 1.2/2.16Tbps 1.92/3.84Tbps
Data Forwarding Capacity 152/200/152Gbps 104/176/576Gbps 1600Gbps 1.92Tbps 960/1728Gbps 3.2/6.4Tbps
Packet Routing Capacity (IPv4/IPv6) 96/150/114Mpps 77/132/432Mpps 1190Mpps 1.4Bpps IPv4 345/630Mpps
IPv6 315/576Mpps
2.38/4.75Bpps
Max. 100-GbE ports N/A 8/16
Max. 10-GbE ports 2(optional) 24 56(optional) 48 68/132 96/192
Max. 1-GbE ports 24/48/24 24 or 48 56(optional) 48 192/384 192/384
Max. OC-192(STM-64) ports N/A 8/14
Max. OC-48(STM-4/16) ports N/A 8/14
Routing Protocols Static, RIP, OSPF, BGP Static, RIP, OSPF, BGP, IS-IS Full L3 & MPLS, VPLS
Height 1RU 6/14RU 5/7RU
Airflow side-to-rear side-to-back(6430, 6450)
front-to-back(6610)
front-to-back side-to-back
Power Supply Redundancy 2 (Internal) 2(External) 2 (Internal) M+N

Application Delivery Switch

Categories ServerIron ADX 1000/1000F ServerIron ADX 4000 ServerIron ADX 10000
Maximun Application Cores 4 16 32
Switch Fabric Capacity 100Gbps 160Gbps 320Gbps
Maximum Gigabit Ethernet Ports 1000:16(Copper)
1000F:24(Copper or SFP)
24(Copper or SFp) 48(Copper or SE)
Maximum 10 Gigabit Ethernet Ports 2 8 16
Maximum System Memory 8GB 32GB 64GB
Maximum DNS Queries/Sec 2,255,000 9,000,000 18,000,000
Layer4 Connections/Sec(HTTP 1.1) 375,000 1,500,000 3,000,000
Layer4 Transactions/Sec(HPPT 1.1) 2,500,000 10,000,000 20,000,000
Layer7 Connections/Sec(HTTP 1.0) 90,000 360,000 720,000
Layer7 Transactions/Sec(HTTP 1.1) 150,000 600,000 1,200,000
Layer4 Aggregate Throughput(Gbps) 9Gbps 35Gbps 70Gbps
Layer7 Aggregate Throughput(Gbps) 9Gbps 35Gbps 70Gbps
Maximum SSL TPS(Transactions/Sec) 28,000 112,00 224,000
Maximum Concurrent Connections 16,000,000 64,000,000 128,000,000
Maximum Concurrent Session Entries 32,000,000 128,000,000 256,000,000
Hardware-based DDoS Protection (Packets/Sec) 15,000,000 60,00,000 120,000,000
Power Supply Redundancy 2 (Internal) M+N M+N

Data Center Switch

Categories VDX 6740/6740T VDX 8770-4 (up to 4 slots) VDX 8770-8 (up to 8 slots)
Switch Fabric Capacity 1.28/1.28Tbps 16Tbps 32Tbps
Switch performance 960/960Mpps 5.76Tbps 11.52Tbps
Port-to-port latency 850ns/3μs 4μs 4μs
Max. 100-GbE ports N/A 24 48
Max. 40 GbE QSFP+
(10 GbE break-out cable)
4/4 108 216
Max. 10-GbE ports 48/48 192 384
Max. 1-GbE ports 48/48 192 384
Routing Protocols Static, OSPF, BGP Static, OSPF, BGP Static, OSPF, BGP
Height 1U 8U 15U
Airflow Front to back Back to front Side-to-back airflow, with front-to-back duct converter option Front to back
Power Supply Redundancy 2 M+N M+N
