보안 솔루션
Security Solution 보안 솔루션

보안 솔루션
네트워크 인프라를 안전하게 지켜줄 글로벌 리딩 보안 솔루션
Radware FireEye MANDIANT hp Vectra Rapid7
FireEye
  • 브로슈어

APT Security solution (No.1 Signature-less Malware Protection)

NX 시리즈

Model NX900 NX1400 NX2400 NX4400(4420) NX7400(7420) NX10000
Vx Engine(FEOS7.0) 4 8 24 48 192
Users 50 100 500 2500 10000 40000
Performance Up to 10Mbps Up to 20Mbps Up to 50Mbps Up to 250Mbps Up to 1Gbps Up to 4Gbps
Rack Half-1U Rack-Mount 1U Rack-Mount 2U Rack-Mount
Dimensions 16.8"x14.0"x1.7" 17.2"x25.6"x1.7" 17.2"x25.6"x3.5" 17.2"x27.9"x3.5"
weight 17 lbs (7.7Kg) 22 lbs (9.9Kg) 30 lbs (13.6Kg) 50 lbs (22.7Kg) 60 lbs (27.2Kg)
Processor Type 2.3GHz/8-Core 3.1GHz/6-Core 3.2GHz/8-Core 2.5GHz/16-Core
Cores 8 6 8 32 64
Nums 1 2 4
Memory 16GB 32GB 64GB 256GB
HDD 1x500GB SATA 2x600GB SAS Drive 2 x 800GB SAS Drive
Bypass Card/NIC YES
P/S 1 (Single 200W) 2 (Single 260W) 2 (Dual 700W) 2 (Dual 1200W)
Monitoring ports 2x10/100/1000 Base-T 4x10/100/1000 Base-T 4x1000 Base-T(1000Base-SX) 2x10G Base-SR/SW
Management ports 2x10/100/1000 Base-T
RAID No RAID 1

AX 시리즈

Model AX5400 AX8400
Vx Engine(FEOS7.0) 48 96
Performance Up to 8,200 / Day Up to 16,000 / Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 16 32
Nums 2
Memory 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Management ports 2x10/100/1000 Base-T
RAID RAID 1

EX 시리즈

Model EX3400 EX5400 EX8400(8420)
Vx Engine(FEOS7.0) 48 96 160
Performance 150,000 Emails/Day 400,000 Emails/Day 750,000 Emails/Day
Performance(TLS) 100,000 Emails/Day 270,000 Emails/Day 500,000 Emails/Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 25 lbs (11.4 Kg) 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 8 16 32
Nums 1 2
Memory 32GB 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Monitoring ports 2x10/100/1000 Base-T 2x1000 Base-T(1000Base-SX)
Management ports 2x10/100/1000 Base-T
RAID RAID 1

FX 시리즈

Model FX5400 FX8400
Vx Engine(FEOS7.0) 96 192
Performance Up to 80,000 Files/Day Up to 160,000 Files/Day
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x27.9"x3.5"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 16 32
Nums 2
Memory 64GB 128GB
HDD 2x600GB SAS Drive
P/S 2 (Dual 700W) 2 (Dual 1400W)
Management ports 2x10/100/1000 Base-T

CM 시리즈

Model CM4400 CM7400 CM9400
Performance Up to 16 Web appliances (12 Web / 1 eMAil / 1 MAS) Up to 40 Web appliances (26 Web / 3 eMail / 1 MAS) Up to 100 Web appliances (48 Web / 5 eMail / 1 MAS)
Rack 1U Rack-Mount 2U Rack-Mount
Dimensions 17.2"x25.6"x1.7" 17.2"x25.6"x3.4"
weight 30 lbs (13.6 Kg) 50 lbs (22.7 Kg)
Processor Type 3.2 Ghz / 8-Core 2.5 Ghz / 16-Core
Cores 8 16 32
Nums 1 2
Memory 64GB 128GB 256GB
HDD 4x600GB SAS Drive 4x800GB SAS Drive
P/S 2 (Dual 700W)
Management ports 2 (Dual 700W)
RAID RAID 10
