구분 | DefensePro 6 | DefensePro 20 | DefensePro 60 | DefensePro 200 | DefensePro 400 |
---|---|---|---|---|---|
Throughput | DP Model 6-02 - 200 Mbps DP Model 6-05 - 500 Mbps DP Model 6-1 - 1 Gbps DP Model 6-2 - 2 Gbps DP Model 6-3 - 3 Gbps |
DP Model 20-2 - 2 Gbps DP Model 20-4 - 4 Gbps DP Model 20-8 - 8 Gbps DP Model 20-12 - 12 Gbps |
DP Model 60-10 - 10 Gbps DP Model 60-20 - 20 Gbps DP Model 60-40 - 40 Gbps |
DP Model 200-80 - 80 Gbps | DP Model 400-160 - 160 Gbps |
최대 누적 세션 | 3,000,000 | 12,000,000 | 18,000,000 | ||
최대 DDoS 방어성능 | 5,800,000 | 25,000,000 PPS | 330,000,000 PPS | ||
지연률 | < 60 Micro Seconds | ||||
100GE 광포트 | - | - | - | 4 (QSFP28) | |
40GE 광포트 | - | - | - | 4 (QSFP+) | |
1GE / 10GE 광포트 | 2 (SFP+) | 24 (SFP+) | 20 (SFP+) | ||
10/100/1000 UTP포트 | 6 | - | - | - | - |
운영모드 | Transparent L2 Forwarding / IP Forwarding | ||||
관리 콘솔 | RJ-45 | ||||
하드웨어 Bypass | 광포트 (외장형 Bypass 별도 구매 필요) / UTP포트 (내장형 Bypass 기능 지원) | 광포트 (외장형 Bypass 별도 구매 필요) | |||
IPv6 지원여부 | 지원 | ||||
전원 장치 | 이중화 전원장치 기본탑재 | ||||
크기(W*D*H) 및 무게 | 436 * 406 * 44mm | 436 * 480 * 88mm (2U) | 424 * 600 * 88mm | ||
(Single PS) / 6kg (Dual PS) / 7kg |
11.2kg | 18.7kg |
모델명 | APSolute Vision ODS-VL2 |
---|---|
CPU | 1 x Intel Quad-CPU |
메모리 | 32 GB |
포트 | 2 x 10 GbE SFP+ 8 x 1 GbE RJ45 |
관리 콘솔 | RJ-45 |
USB | On front panel |
SSD | 500 GB |
크기(W*D*H) 및 무게 | 436 * 406 * 44mm (1U) / 6 kg |
